Microtek
Leading Manufacturers, Exporters, Wholesaler and Retailer of Solar Bi-Directional Hybrid System, Solar Grid-Tied System, Solar UNI-Directional Hybrid UPS, UPS EB Digital and UPS SEBz Sinewave from Coimbatore.
| Business Type | Manufacturer, Supplier, Retailer |
| Capacity (Rated Output Power) | 3000 Watts |
| Capacity (Maximum PV Array Power) | 4000 Watts |
Microtek M-SUN SOLAR BI-DIRECTIONAL HYBRID SYSTEM is a system with Grid-Tie functionality and Dual Power Inputs.
MPPT Based Technology Grid Tie Wall mounted Hybrid System that converts Solar Energy into Electricity.
It stores the Energy in Battery and provides the Electricity when Power is not available.
Excess Generation of Electricity from Solar Panel will be exported to Utility Grid if there is active Net Metering Policy in State.
- Pure Sinewave Output
- Self-Consumption and Feed-in to the Grid.
- Programmable Supply Priority for PV, Battery or Grid.
- Programmable Multiple Operations Models: Off-Grid and Grid-Tie with Backup.
- Monitoring Software for Real-Time Status Display and Control.
- User-adjustable Battery Charging Current and Voltage.
- Parallel operation upto 6 Units only.
| Business Type | Manufacturer, Supplier, Retailer |
Microtek M-SUN SOLAR GRID-TIED SYSTEM is a system with Grid-Tie functionality.
MPPT Based Technology Grid Tie Wall mounted Solar System that converts Solar Energy into Electricity.
Excess Generation of Electricity from Solar Panel will be exported to Utility Grid if there is active Net Metering Policy in State.
Key features- Max 97.6% Efficiency, Real Time Precise MPPT algorithm for BEST Performance.
- Plug & Play Easy Installation & Maintenance, IP65 for Free Site Selection.
- Big Size LCD Display, Interface Selection, RS485 for System Monitoring.
- Intelligent Grid Management, Reactive Power Capability & Self Power Reducer when Over Frequency. Remote Active/Reactive Power Limit Control.
- SD Card inside for Data Storage upto 25 Years.
| Business Type | Manufacturer, Supplier, Retailer |
Microtek M-SUN SOLAR UNI-DIRECTIONAL HYBRID UPS is designed to utilize maximum use of Solar Energy. If there is excess of Solar Energy Generation from PV
| Business Type | Manufacturer, Supplier, Retailer |
| Weight | 9.200kg |
| Dimensions (L W H) | 382x340x198 |
| Rated Capacity | 600 VA |
| Output Power | 510 Watts |
| Battery | 1 Battery System (12V) |
| Wave form | TPZi Waveform (Trape Zoidal) |
| Warranty | 2 Years |
MICROTEK UPS EB Series is Micro Controller design based , LARGEST SELLING SERIES of Extended Backup External Battery UPS Systems. It comes with many user friendly features. It has Voltage Range Selection Switch and can be operated in Standard Voltage Range from 100V~300V and Narrow Voltage Range from 180V~260V.
- Micro controlled based Intelligent Control Design.
- Display Indications (Status & Fault)
- CCCV Technology with Auto Trickle Mode
- SmartOverload Sense and Short Circuit Protection
- Battery State Monitoring
- Multi Stage Battery Charger
- Mains Input Voltage Range Selection
| Business Type | Manufacturer, Supplier, Retailer |
| Rated Capacity | 900 VA / 12V |
| Output Power | 725 Watts |
| Battery | 1 Battery System (12 VDC) |
| Waveform | Pure Sinewave |
| Warranty | 2 Years |
MICROTEK UPS SEBz Series is Micro Controller design based , LARGEST SELLING SERIES of Extend-ed Backup External Battery UPS Systems. It comes with many user friendly features. It has Voltage Range Selection Switch and can be operated in Standard Voltage Range from 100V~300V and Narrow Voltage Range from 180V~260V.
UPS SEBz Series Models are based on Intelli Pure Sinewave Technology which ensures Noiseless,Safe and Efficient Performance along with Longer Backup
- Micro Controller Based Intelligent Control Design.
- LED Display Indications (Status & Fault)
- CCCV Technology with Auto Trickle Mode
- Smart Overload Sense and Short Circuit Protection
- Battery State Monitoring
- Multi-Stage Battery Charger
- Mains Input Voltage Range Slide Selection Switch
- MAINS ON
- UPS ON
- BATTERY CHARGING
- OVERLOAD
- BATTERY LOW
- FAULT INDICATION
- Over Load/Short Circuit Protection: If the UPS is excessively Overloaded in UPS Mode or encounters a Short Circuit, it will go into Protection Mode. The Output will Shut Down in this case.
- Battery Deep Discharge/Over Charge Protection: The UPS has In-built Electronic Protection Circuit that protects the Batteries from getting Deep Discharged or Over Charged.
